PREVOST - British (Type 19 / PCL) Quick Release Safety Coupling Parallel Male Thread BSI 06

Sale price Price £15.76 Regular price Unit price  per

Prevost -  British (Type 19 / PCL) Quick Release Safety Coupling Parallel Male Thread BSI 06

The Prevost parallel male threaded british quick release coupling, also known as a type 19 or a PCL coupling, is a "one push" safety coupling (avoids hose whip), made of a non scratch, anti static composite material. The parallel male threaded british quick release safety coupling has an operating pressure of 2-12 bar, a temperature range of -15°C to +70°C and a id passage of 6mm that allows flow rates at 6 bar of 750 l/min (ΔP = 0,6 bar).

  • Body: Composite
  • "One Push" Safety System
  • Compact and lightweight
  • Colour coded
  • UV and heat-resistant
  • Very low pressure loss
  • Cost-effective
  • Corrosion Resistant
  • BSP Parallel Thread

Fitting Size Dimension A
Dimension B Dimension C
G 1/4"
83.9mm 30mm 20mm
G 3/8"
83.9mm 30mm 23mm
G 1/2"
89.9mm 30mm 26mm

Click here to download the Product Sheet.
