Open image in slideshow, PREVOST - British (Type 19 / PCL) Quick Release Safety Coupling Hose Tail BSI 06

PREVOST - British (Type 19 / PCL) Quick Release Safety Coupling Hose Tail BSI 06

£15.76

Prevost - British (Type 19 / PCL) Quick Release Safety Coupling Hose Tail BSI 06

The Prevost hose tail british quick release coupling, also known as a type 19 or a PCL coupling, is a "one push" safety coupling (avoids hose whip), made of a non scratch, anti static composite material. The hose tail british quick release safety coupling has an operating pressure of 2-12 bar, a temperature range of -15°C to +70°C and a id passage of 6mm that allows flow rates at 6 bar of 750 l/min (ΔP = 0,6 bar).

  • Body: Composite
  • "One Push" Safety System
  • Compact and lightweight
  • Colour coded
  • UV and heat-resistant
  • Very low pressure loss
  • Cost-effective
  • Corrosion Resistant

ID Hose Size Dimension A
 Dimension B Dimension C
6mm 90.6mm 30mm 19.4mm
8mm
 90.6mm 30mm 19.4mm
10mm
 90.6mm 30mm 19.4mm
13mm 95.6mm 30mm 19.4mm

Click here to download the Product Sheet.

Delivery and Availability:

Estimated standard delivery 2-3 working days dependant on stock.

All delivery times are dependent on stock, please give us a call on 01489 785394 to discuss availability when ordering large quantities.



If you require any further information, or are unsure whether you require Prevost fittings or which fittings are best for your needs, please feel free to contact us via email on sales@altoncompressorservices.co.uk
